Enclosed Power Relay, 4Pin, 120VAC, SPST-NO

schneider Part No : 9AS5A52-120

Item - Relay: Enclosed Power Relay

Coil Volts: 120V AC

AC Contact Rating - Relay: 15A @ 240V (NC), 30A @ 240V (NO)

  • Description
  • Specifications

Enclosed Power Relay, Coil Volts 120V AC, AC Contact Rating - Relay 30A @ 240V, DC Contact Rating - Relay 30A @ 28V, Number of Pins - Relay 4, Contact Form - Relay SPST-NO, Mounting - Relay Bottom Flange, Power Consumption - Relay 2.8 VA, Contact Material Silver Alloy, Electrical Connection - Power Relay 1/4 in Tab Terminal


  • Coil Volts: 120V AC
  • AC Contact Rating - Relay: 30A @ 240V
  • DC Contact Rating - Relay: 30A @ 28V
  • Number of Pins - Relay: 4
  • Contact Form - Relay: SPST-NO
  • Mounting - Relay: Bottom Flange
  • Power Consumption - Relay: 2.8 VA
  • Contact Material: Silver Alloy
  • Electrical Connection - Power Relay: 1/4 in Tab Terminal
  • HP @ 120V: 1
  • HP @ 240V: 2
  • Body Depth - Relay: 1.95 in
  • Hz: 50/60
  • Electrical Connection: 1/4" Tab Terminal
  • Dimensions: 1.10"H, 1.06"W, 1.95"D
