Cylindrical Photoelectric Sensor Transmitter, Sensing Method - Cylindrical Photoelectric Sensor Through Beam Transmitter, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 10 to 36V DC, Electrical Connection - Cylindrical Photoelectric Sensor 4-Pin M12 Male Connector, Circuit Type - Cylindrical Photoelectric Sensor NPN/PNP
- IP Rating: 67
- Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
- Operating Frequency: 1,000 Hz
- Electrical Connection: Quick Disconnect M12 Connector
- Power Requirement - Cylindrical Photoelectric Sensor: 10 to 36V DC
- Electrical Connection - Cylindrical Photoelectric Sensor: 4-Pin M12 Male Connector
- Diameter: 18mm
- Features: PMMA Lens, Reverse Polarity Protection
- Max. Sensing Distance - Cylindrical Photoelectric Sensor: Transmitter
- NEMA Rating: Not Rated
- Sensing Method: Through Beam Transmitter
- Diameter - Cylindrical Photoelectric Sensor: 18 mm
- Body Material: 316L Stainless Steel/1.4404, PA, EPDM
- Light Source: Red LED
- Length - Cylindrical Photoelectric Sensor: 72 mm
- Shape: Cylindrical
- Power Requirement: 10 to 36VDC
- Operation Mode: Selectable Light On/Dark On
- Standards: CE Approval, CUL Listed, UL Listed
- Operating Temp. Range: -25 Degrees to 80 Degrees C
- Circuit Type - Cylindrical Photoelectric Sensor: NPN/PNP
- Min. Object Size: 1000mm dia Light Spot
- Sensing Method - Cylindrical Photoelectric Sensor: Through Beam Transmitter
- Length: 72.00mm
