Solid State Relay, 180 to 280VAC, 50A

schneider Part No : SSP3A250P7T

Item - Relay: Solid State Relay

Input or Control Voltage: 180 to 280V AC

Output or Controlled Voltage Range: 48 to 530V AC

Solid State Relay, Input or Control Voltage 180 to 280V AC, Output or Controlled Voltage Range 48 to 530V AC, Max. Output Amps w/Heat Sink 50, Heat Sink Not Included, Switch Type SCR, Contact Form - Relay (3) SPST-NO, Relay Turns On At Zero Crossing, Input Power Consumption (Burden) 5.6VA, Mounting - Relay Surface, Finger Safe Yes


  • Input or Control Voltage: 180 to 280V AC
  • Output or Controlled Voltage Range: 48 to 530V AC
  • Max. Output Amps w/Heat Sink: 50
  • Heat Sink: Not Included
  • Switch Type: SCR
  • Contact Form - Relay: (3) SPST-NO
  • Relay Turns On At: Zero Crossing
  • Input Power Consumption (Burden): 5.6VA
  • Mounting - Relay: Surface
  • Input Voltage: 180 to 280VAC
  • Voltage Output: 48 to 530VAC
  • Item: Solid State Relay
  • Body Depth - Relay: 3.14 in
  • Case Color: Dark Gray
  • Standards: CE, CSA, RoHS, UL
  • Body Width - Relay: 4.0 in
  • Input or Control Voltage Range: 180 to 280VAC
