Photoelectric-Sensor-Cylindrical-Diffuse-E3FA-DP21

Photoelectric Sensor, Cylindrical, Diffuse

Omron Part No : E3FA-DP21

Item: Cylindrical Photoelectric Sensor

IP Rating: 69K

Width: 0.75"

Description
Specifications

Cylindrical Photoelectric Sensor, Sensing Method - Cylindrical Photoelectric Sensor Diffuse, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 5 to 30V DC, Electrical Connection - Cylindrical Photoelectric Sensor 4-Pin M12 Male Connector, Circuit Type - Cylindrical Photoelectric Sensor PNP, Max. Sensing Distance - Cylindrical Photoelectric Sensor 100 mm

IP Rating: 69K
Width: 0.75"
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Depth: 3.25"
Max. Load Current: 100 mA
Electrical Connection: M12 Connector
Circuit Type - Cylindrical Photoelectric Sensor: PNP
Body Material: ABS Plastic
Operating Temp. Range: -25 Degrees to 55 Degrees C
Diameter - Cylindrical Photoelectric Sensor: 18 mm
Diameter: 18mm
Length: 45mm
Max. Sensing Distance: 100mm
Power Requirement: 5 to 30VDC
Max. Sensing Distance - Cylindrical Photoelectric Sensor: 100 mm
Power Requirement - Cylindrical Photoelectric Sensor: 5 to 30V DC
Electrical Connection - Cylindrical Photoelectric Sensor: 4-Pin M12 Male Connector
Features: High Power Red LED for Easy Sensor Alignment and Dependable Outputs In Dusty Environments
Standards: CE Approval
Min. Object Size: 75mm dia Opaque
Length - Cylindrical Photoelectric Sensor: 45 mm
Shape: Cylindrical
Operation Mode: Selectable Light On/Dark On
Sensing Method - Cylindrical Photoelectric Sensor: Diffuse
Light Source: Red LED
Sensing Method: Diffuse
NEMA Rating: IP69K

Photoelectric Sensor, Cylindrical, Diffuse
