Photoelectric-Sensor-Rectangle-Thru-Beam-E3Z-T61

Photoelectric Sensor, Rectangle, Thru-Beam

Omron Part No : E3Z-T61

Item: Photoelectric Sensor

Circuit Type: NPN

Sensing Method - Rectangular Photoelectric Sensor: Through Beam Set

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Through Beam Set, Power Requirement - Rectangular Photoelectric Sensor 12 to 24V DC, Output Circuit Type - Rectangular Photoelectric Sensor NPN, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Max. Sensing Distance - Rectangular Photoelectric Sensor 15.0 m, Electrical Connection - Rectangular Photoelectric Sensor 2m Cable

Circuit Type: NPN
Sensing Method - Rectangular Photoelectric Sensor: Through Beam Set
IP Rating: 67
Power Requirement - Rectangular Photoelectric Sensor: 12 to 24V DC
Width: 0.41"
Output Circuit Type - Rectangular Photoelectric Sensor: NPN
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Depth: 0.79"
Max. Sensing Distance - Rectangular Photoelectric Sensor: 15 m
Max. Load Current: 100 mA
Electrical Connection - Rectangular Photoelectric Sensor: 2m Cable
Height - Rectangular Photoelectric Sensor: 30 mm
Electrical Connection: 2m cable
Body Material: PBT
Operating Temp. Range: -25 Degrees to 55 Degrees C
Power Requirement: 12 to 24VDC
Footnotes: 4
Width - Rectangular Photoelectric Sensor: 10 mm
Features: Output Short Circuit and Power Supply Reverse Polarity Protection
Operation Mode: Selectable Light On/Dark On
Response Time: 1.0 msec
Max. Sensing Distance: 15m
Light Source: Infrared LED
Min. Object Size: 12mm dia Opaque
Length: 1.20"
Shape: Rectangular
Sensing Method: Through Beam
Depth - Rectangular Photoelectric Sensor: 20 mm
Standards: CE Approval

Photoelectric Sensor, Rectangle, Thru-Beam
