Photoelectric-Sensor-Rectangle-Thru-Beam-E3T-ST11

Photoelectric Sensor, Rectangle, Thru-Beam

Omron Part No : E3T-ST11

Item: Photoelectric Sensor

Sensing Method - Rectangular Photoelectric Sensor: Through Beam Set

IP Rating: 67

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Through Beam Set, Power Requirement - Rectangular Photoelectric Sensor 12 to 24V DC, Output Circuit Type - Rectangular Photoelectric Sensor NPN, Operating Mode - Photoelectric Sensor Light On, Max. Sensing Distance - Rectangular Photoelectric Sensor 1.0 m, Electrical Connection - Rectangular Photoelectric Sensor 2m Cable, Height - Rectangular Photoelectric Sensor 19 mm

Sensing Method - Rectangular Photoelectric Sensor: Through Beam Set
IP Rating: 67
Circuit Type: NPN
Power Requirement - Rectangular Photoelectric Sensor: 12 to 24V DC
Width: 0.27"
Output Circuit Type - Rectangular Photoelectric Sensor: NPN
Depth: 0.37"
Operating Mode - Photoelectric Sensor: Light On
Max. Sensing Distance - Rectangular Photoelectric Sensor: 1 m
Max. Load Current: 50 mA
Electrical Connection - Rectangular Photoelectric Sensor: 2m Cable
Electrical Connection: 2m cable
Height - Rectangular Photoelectric Sensor: 19 mm
Min. Object Size: 2mm dia Opaque
Features: Output Short-Cut And Output Reverse Polarity Protection, Surge Suppressor
Operation Mode: Light On
Body Material: PBT
Footnotes: 4
Standards: CE Approval
Light Source: Red LED
Length: 0.73"
Power Requirement: 12 to 24VDC
Max. Sensing Distance: 1m
Response Time: 1.0 msec
Depth - Rectangular Photoelectric Sensor: 9 mm
Shape: Rectangular
Operating Temp. Range: -25 Degrees to 55 Degrees C
Width - Rectangular Photoelectric Sensor: 7 mm
Sensing Method: Through Beam

Photoelectric Sensor, Rectangle, Thru-Beam
