Photoelectric-Sensor-Rectangular-Diffuse-E3SCD11

Photoelectric Sensor, Rectangular, Diffuse

Omron Part No : E3SCD11

Item: Photoelectric Sensor

Sensing Method - Rectangular Photoelectric Sensor: Diffuse

IP Rating: 67

Description
Specifications

Photoelectric Sensor, Shape - Rectangular Photoelectric Sensor Rectangular, Sensing Method - Rectangular Photoelectric Sensor Diffuse, Power Requirement - Rectangular Photoelectric Sensor 10 to 30V DC, Output Circuit Type - Rectangular Photoelectric Sensor NPN/PNP, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Max. Sensing Distance - Rectangular Photoelectric Sensor 700 mm, Electrical Connection - Rectangular Photoelectric Sensor 2m Cable

Item: Photoelectric Sensor
Sensing Method - Rectangular Photoelectric Sensor: Diffuse
IP Rating: 67
Circuit Type: NPN/PNP
Power Requirement - Rectangular Photoelectric Sensor: 10 to 30V DC
Width: 0.91"
Output Circuit Type - Rectangular Photoelectric Sensor: NPN/PNP
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Depth: 1.97"
Max. Sensing Distance - Rectangular Photoelectric Sensor: 700 mm
Max. Load Current: 100 mA
Electrical Connection - Rectangular Photoelectric Sensor: 2m Cable
Height - Rectangular Photoelectric Sensor: 20 mm
Electrical Connection: 2m cable
Length: 0.80"
Depth - Rectangular Photoelectric Sensor: 50 mm
Response Time: 1.0 msec
Shape: Rectangular
Max. Sensing Distance: 700mm
Sensing Method: Diffuse
Operation Mode: Selectable Light On/Dark On
Width - Rectangular Photoelectric Sensor: 23 mm
Standards: CE Approval
Features: Output Short-Cut And Output Reverse Polarity Protection, Surge Suppressor
Footnotes: 3,4
Light Source: Infrared LED
Power Requirement: 10 to 30VDC
NEMA Rating: 4X, 6P
Operating Temp. Range: -25 Degrees to 55 Degrees C
Body Material: Die Cast Zinc

Photoelectric Sensor, Rectangular, Diffuse
