Photocontrol, 105 to 305VAC, Turn-Lock

Intermatic Part No : EK4536

Mounting: Turn-Lock
For Use With: Area Lightning, Floodlights, Roadways, Variable Sky Conditions
Voltage: 105 to 305V AC
Max. Wattage: 1,000
Max. Ballast Amps: 6.0
Foot Candles On: 1.2 to 3.0
Foot Candles Off: 2 to 5

Photocontrol, Mounting Turn-Lock, Voltage 105 to 305V AC, Max. Wattage 1,000, Max. Ballast Amps 6.0, 1.2 to 3.0 Foot Candles On, 2 to 5 Foot Candles Off, Color Translucent, Temp. Range -40 Degrees to 158 Degrees F, Length 5 51/64 in, Width 3 1/2 in, Depth 3 1/2 in, Enclosure Type Raintight, Contact Form SPST, Housing Material Polycarbonate, Setting Dusk to Dawn, Standards CSA, cUS, RoHS, Includes Locking Nut, Washer Gasket


  • Mounting: Turn-Lock
  • For Use With: Area Lightning, Floodlights, Roadways, Variable Sky Conditions
  • Voltage: 105 to 305V AC
  • Max. Wattage: 1,000
  • Max. Ballast Amps: 6.0
  • Foot Candles On: 1.2 to 3.0
  • Foot Candles Off: 2 to 5
  • Color: Translucent
  • Temp. Range: -40 Degrees to 158 Degrees F
  • Contact Form: SPST
  • Includes: Locking Nut, Washer Gasket
  • Length: 5 51/64 in
  • Housing Material: Polycarbonate
  • Enclosure Type: Raintight
  • Standards: CSA, cUS, RoHS
  • Width: 3 1/2 in
  • Manufacturers Warranty Length: 8 yr
